The visualization

Navigating in the plan

The VAPS offers various options of adjusting the size of your working area and going directly to a specific position in your plan

Adjust the time scale

Depending on how much detail or summary is required, you can either increase or reduce the time scale solution by mouse wheel or touch pad.

VAPS_timescale_solution

Show operations of of a certain timespan only

Click the according item to show either

  • all operations of your current work day
  • all operations within a week starting from the current workdate
  • all operations of a month starting from the current workdate
VAPS_Timescale_menu

Scrolling

The VJS offers the following options for quickly navigating to specific positions in the diagram:

    • the common scrolling options by vertical and/or horizontal scrollbar
    • dragging the timescale either right or left by mouse

      VAPS_timescale_drag
    • scroll directly to the Dynamics 365 Business Central work date by selecting the corresponding item from the “Actions” menu.

      VAPS_scrolltoworkdate

Adjust the width ratio between table and diagram

You can modify the width ratio between the table and the diagram by moving the vertical splitter bar between them.

VAPS_width_ratio

Return to default time range

Select "Fit into view" to switch directly to the timescale as defined in the simulation's settings.
